TANK 1900
|
Axes Configuration |
- |
4-Axes |
5-Axes |
5-Axes Multitasking |
|
|
Process Technology |
- |
Milling |
Milling |
Milling, Turning, Grinding |
|
|
Working Area |
X-Axis Stroke Y-Axis Stroke Z-Axis Stroke X/Y/Z Axis Rapid Feed |
mm mm mm m/min |
1.900 1.400 1.960 50 |
1.900 1.400 1.960 50 |
1.900 1.400 1.960 50 |
|
Pallet |
Option 1 Option 2² |
mm mm |
1.000 x 1.000 1.250 x 1.250 |
1.000 x 1.000 1.250 x 1.250 |
Ø 1.250 Ø 1.400 |
|
Rotary Table (B-Axis) |
Max. Rotation Speed |
min-1 |
20 / 40 |
20 / 40 |
500 |
|
5th Axis (A-Axis) |
Type Tilting Angle |
- Degrees |
- - |
Tilting Head 175 (+80/-95) |
Tilting Head 175 (+80/-95) |
|
Spindle Unit |
Tool-Taper Speed Range |
- min-1 |
HSK / ISO / CAPTO from 6.000 up to 30.000 |
||
|
Tool-Magazine |
Capacity (up to)1 |
No. |
80 (999) |
80 (999) |
80 (999) |
|
Available Configurations |
Single-Pallet / Twin-Pallet / Multi-Pallet / FMS |
TANK 1600
|
Axes Configuration |
- |
4-Axes |
5-Axes |
5-Axes Multitasking |
|
|
Process Technology |
- |
Milling |
Milling |
Milling, Turning, Grinding |
|
|
Working Area |
X-Axis Stroke Y-Axis Stroke Z-Axis Stroke X/Y/Z Axis Rapid Feed |
mm mm mm m/min |
1.600 1.400 1.500 50 |
1.600 1.400 / 1.500 1.600 / 1.960 50 |
1.600 1.400 / 1.500 1.560 / 1.960 50 |
|
Pallet |
Option 1 Option 2² |
mm mm |
800 x 1.000 1.000 x 1.000 |
800 x 1.000 1.000 x 1.000 |
Ø 1.000 Ø 1.250 |
|
Rotary Table (B-Axis) |
Max. Rotation Speed |
min-1 |
20 / 40 |
20 / 40 |
500 |
|
5th Axis (A-Axis) |
Type Tilting Angle |
- Degrees |
- - |
Tilting Head 175 (+80/-95) |
Tilting Head 175 (+80/-95) |
|
Spindle Unit |
Tool-Taper Speed Range |
- min-1 |
HSK / ISO / CAPTO from 6.000 up to 30.000 |
||
|
Tool-Magazine |
Capacity (up to)1 |
No. |
80 (999) |
80 (999) |
80 (999) |
|
Available Configurations |
Single-Pallet / Twin-Pallet / Multi-Pallet / FMS |
TANK 1300
|
Axes Configuration |
- |
4-Axes |
5-Axes |
5-Axes Multitasking |
|
|
Process Technology |
- |
Milling |
Milling |
Milling, Turning, Grinding |
|
|
Working Area |
X-Axis Stroke Y-Axis Stroke Z-Axis Stroke X/Y/Z Axis Rapid Feed |
mm mm mm m/min |
1.300 1.300 1.300 50 |
1.300 1.400 1.400 50 |
1.300 1.400 1.560 50 |
|
Pallet |
Option 1 Option 2² |
mm mm |
630 x 800 800 x 800 |
630 x 800 800 x 800 |
Ø 860 Ø 1.000 |
|
Rotary Table (B-Axis) |
Max. Rotation Speed |
min-1 |
20 / 40 |
20 / 40 |
500 |
|
5th Axis (A-Axis) |
Type Tilting Angle |
- Degrees |
- - |
Tilting Head 175 (+80/-95) |
Tilting Head 175 (+80/-95) |
|
Spindle Unit |
Tool-Taper Speed Range |
- min-1 |
HSK / ISO / CAPTO from 6.000 up to 30.000 |
||
|
Tool-Magazine |
Capacity (up to)1 |
No. |
80 (999) |
80 (999) |
80 (999) |
|
Available Configurations |
Single-Pallet / Twin-Pallet / Multi-Pallet / FMS |
TANK 1000 EVO
|
Axes Configuration |
- |
5-Axes |
5-Axes Multitasking |
|
|
Process Technology |
- |
Milling |
Milling, Turning, Grinding |
|
|
Working Area |
X-Axis Stroke Y-Axis Stroke Z-Axis Stroke X/Y/Z Axis Rapid Feed |
mm mm mm m/min |
1.200 1.000 1.100 75 |
1.200 1.000 1.100 75 |
|
Pallet |
Option 1 Option 2² |
mm mm |
630 x 630 630 x 800 |
Ø 800 - |
|
Rotary Table (B-Axis) |
Max.Rotation Speed |
min-1 |
100 |
100 / 800 |
|
5th Axis (A-Axis) |
Type Tilting Angle |
- Degrees |
Tilting Head 180 (+80/-100) |
Tilting Head 180 (+80/-100) |
|
Spindle Unit |
Tool-Taper Speed Range |
- min-1 |
HSK / ISO / CAPTO from 14.000 up to 18.000 |
|
|
Tool-Magazine |
Capacity (up to)1 |
No. |
89 (999+) |
89 (999+) |
|
Available Configurations |
Single-Pallet / Twin-Pallet/ Multi-Pallet / FMS |
