TANK.G 3000
|
Axes Configuration |
- |
4-Axes |
5-Axes |
5-Axes Multitasking |
|
|
Process Technology |
- |
Milling |
Milling |
- |
|
|
Working Area |
X-Axis Stroke Y-Axis Stroke Z-Axis Stroke X/Y/Z Axis Rapid Feed |
mm mm mm m/min |
3.000 2.500 2.500 40 - 40 - 32 |
3.000 2.500 2.500 40 - 40 - 32 |
- - - - |
|
Pallet |
Option 1 Option 2 2 |
mm mm |
1.250 x 1.250 1.250 x 1.600 |
1.250 x 1.250 1.250 x 1.600 |
- - |
|
Rotary Table (B-Axis) |
Max. Rotation Speed |
min-1 |
2024/8/15 |
2024/8/15 |
- |
|
5th Axis (A-Axis) |
Type Tilting Angle |
- Degrees |
- - |
Tilting Head 175 (+80/-95) |
- - |
|
Spindle Unit |
Tool-Taper Speed Range |
- min-1 |
HSK / ISO / CAPTO from 6.000 up to 30.000 |
HSK / ISO / CAPTO from 6.000 up to 30.000 |
- - |
|
Tool-Magazine |
Capacity (up to)1 |
No. |
80 (999) |
80 (999) |
- |
|
Available Configurations |
Single-Pallet / Twin-Pallet / Multi-Pallet / FMS |
TANK.G 2600
|
Axes Configuration |
- |
4-Axes |
5-Axes |
5-Axes Multitasking |
|
|
Process Technology |
- |
- |
Milling |
Milling, Turning, Grinding |
|
|
Working Area |
X-Axis Stroke Y-Axis Stroke Z-Axis Stroke X/Y/Z Axis Rapid Feed |
mm mm mm m/min |
2.600 2.000 2.000 40 |
2.600 1.700 2.000 40 |
2.600 1.700 2.000 45 |
|
Pallet |
Option 1 Option 2² |
mm mm |
1.000 x 1.000 1.250 x 1.250 |
1.000 x 1.000 1.250 x 1.250 |
Ø 1.000 Ø 1.250 |
|
Rotary Table (B-Axis) |
Max. Rotation Speed |
min-1 |
20 |
20 |
200 |
|
5th Axis (A-Axis) |
Type Tilting Angle |
- Degrees |
- - |
Tilting Head 175 (+80/-95) |
Tilting Head 175 (+80/-95) |
|
Spindle Unit |
Tool-Taper Speed Range |
- min-1 |
HSK / ISO / CAPTO from 6.000 up to 30.000 |
||
|
Tool-Magazine |
Capacity (up to)1 |
No. |
80 (999) |
80 (999) |
80 (999) |
|
Available Configurations |
Single-Pallet / Twin-Pallet / Multi-Pallet / FMS |
TANK.G 2000
|
Axes Configuration |
- |
4-Axes |
5-Axes |
5-Axes Multitasking |
|
|
Process Technology |
- |
- |
Milling |
Milling, Turning, Grinding |
|
|
Working Area |
X-Axis Stroke Y-Axis Stroke Z-Axis Stroke X/Y/Z Axis Rapid Feed |
mm mm mm m/min |
2.000 2.000 2.000 45 |
2.000 1.700 2.000 45 |
2.000 1.700 2.000 45 |
|
Pallet |
Option 1 Option 2² |
mm mm |
1.000 x 1.000 1.250 x 1.250 |
1.000 x 1.000 1.250 x 1.250 |
Ø 1.000 Ø 1.250 |
|
Rotary Table (B-Axis) |
Max. Rotation Speed |
min-1 |
20 |
20 |
200 |
|
5th Axis (A-Axis) |
Type Tilting Angle |
- Degrees |
- - |
Tilting Head 175 (+80/-95) |
Tilting Head 175 (+80/-95) |
|
Spindle Unit |
Tool-Taper Speed Range |
- min-1 |
HSK / ISO / CAPTO from 6.000 up to 30.000 |
||
|
Tool-Magazine |
Capacity (up to)1 |
No. |
80 (999) |
80 (999) |
80 (999) |
|
Available Configurations |
Single-Pallet / Twin-Pallet / Multi-Pallet / FMS |
TANK.G 1600
|
Axes Configuration |
- |
4-Axes |
5-Axes |
5-Axes Multitasking |
|
|
Process Technology |
- |
- |
Milling |
Milling, Turning, Grinding |
|
|
Working Area |
X-Axis Stroke Y-Axis Stroke Z-Axis Stroke X/Y/Z Axis Rapid Feed |
mm mm mm m/min |
- - - - |
1.600 1.500 2.000 50 |
1.600 1.500 1.960 50 |
|
Pallet |
Option 1 Option 2² |
mm mm |
- - |
1.000 x 1.000 1.250 x 1.250 |
Ø 1.000 Ø 1.250 |
|
Rotary Table (B-Axis) |
Max. Rotation Speed |
min-1 |
- |
20 |
500 |
|
5th Axis (A-Axis) |
Type Tilting Angle |
- Degrees |
- - |
Tilting Head 175 (+80/-95) |
Tilting Head 175 (+80/-95) |
|
Spindle Unit |
Tool-Taper Speed Range |
- min-1 |
- - |
HSK / ISO / CAPTO from 6.000 up to 30.000 |
|
|
Tool-Magazine |
Capacity (up to)1 |
No. |
- |
80 (999) |
80 (999) |
|
Available Configurations |
- |
- |
Single-Pallet / Twin-Pallet / Multi-Pallet / FMS |
